Simulate your first Lightning transaction on the Bitcoin regtest network Part 2 (MacOS)

📜Objective

The goal of this article is to help you

confirm that we have the correct bitcoin.conf settings
spin up a Bitcoin network
Ensure we are on the regtest network
Prepare the first lightning node aka lnd1 for some action
- Spin up node
- Create wallet
- Get some information about the node
- Generate an Address
- Fund the lnd1 wallet with some bitcoin
  - load up our existing local Bitcoin wallet
  - send some bitcoin to generated lnd1 wallet address (to be sent to lnd2 later on)
- Check wallet balance
Prepare the second lightning node aka lnd2 for some action

📜 Introduction

Welcome to Part 2 of our series, fellow Bitcoin/Lightning developers. I'm sure you're itching for some action...

This is the second part of a two-part series and in case you haven't already read the first part go over here Part 1 so you can fully maximize this second part.

📜 Some boring but very important stuff to get us started

The Lightning Network is a second-layer protocol built on top of the Bitcoin blockchain and it enables faster and cheaper transactions by creating off-chain payment channels between users. These channels allow multiple transactions to occur without needing to be recorded on the main Bitcoin blockchain. Instead, only the opening and closing transactions of the channel are settled on the blockchain.

The Regtest (regression test) Bitcoin network mode creates a local private blockchain where you can adjust the parameters to what you want. For this demonstration, we would run our lightning network on top of an active Bitcoin network running a local private blockchain (regtest)

Quick note: throughout this article, long output codeblock data are truncated

The easy part:

⚙️ Confirming our Bitcoin environment and spinning up a Bitcoin daemon

To confirm that our settings are correct to spin up the required Bitcoin network mode, open up the autogenerated bitcoin.conf located at /Users/user/Library/Application Support/Bitcoin/bitcoin.conf with a text editor

Command:

nvim /Users/user/Library/Application Support/Bitcoin/bitcoin.conf

Output:

# Daemon Options
server=1
daemon=1
fallbackfee=0.00072
txindex=1
mintxfee=0.0001
txconfirmtarget=6

# Network Options
regtest=1
#signet=1
#testnet=1

[regtest]
# RPC Options
rpcport=18443
rpcuser=bitcoin
rpcpassword=bitcoin

# ZMQ Options
zmqpubrawblock=tcp://127.0.0.1:28332
zmqpubrawtx=tcp://127.0.0.1:28333
zmqpubhashtx=tcp://127.0.0.1:28332
zmqpubhashblock=tcp://127.0.0.1:28332

Now let's follow through the following steps

📜 Spin up a Bitcoin network (regtest network)

Command:

bitcoind

Output:

Bitcoin Core starting

📜 Ensure we are on the regtest network

Command:

bitcoin-cli  getblockchaininfo

output:

{
  "chain": "regtest",  // 👈🏿 just making sure we are on the 'regtest' network
  "blocks": 526,
  "headers": 526,
...
}

📜 Prepare the first lightning node aka `lnd1` for some action

We'll be preparing our first lightning node now so go ahead and open up two new shell tabs or terminal windows and follow the following steps to spin up both of our previously configured lightning nodes respectively.

First Tab:

Let's go ahead and start up our first node

command:

lnd1

output:

2024-02-14 02:38:18.958 [INF] LTND: Version: 0.17.0-beta commit=fn/v1.0.1-85-ge31d15989, build=production, logging=default, debuglevel=info
2024-02-14 02:38:18.958 [INF] LTND: Active chain: Bitcoin (network=regtest)
2024-02-14 02:38:18.958 [INF] RPCS: Generating TLS certificates...
2024-02-14 02:38:18.960 [INF] RPCS: Done generating TLS certificates
2024-02-14 02:38:18.961 [INF] RPCS: RPC server listening on 127.0.0.1:10009
2024-02-14 02:38:18.963 [INF] RPCS: gRPC proxy started at 127.0.0.1:8080
2024-02-14 02:38:18.963 [INF] LTND: Opening the main database, this might take a few minutes...
2024-02-14 02:38:18.963 [INF] LTND: Opening bbolt database, sync_freelist=false, auto_compact=false
2024-02-14 02:38:19.003 [INF] LTND: Creating local graph and channel state DB instances
2024-02-14 02:38:19.069 [INF] CHDB: Checking for schema update: latest_version=31, db_version=31
2024-02-14 02:38:19.069 [INF] CHDB: Checking for optional update: prune_revocation_log=false, db_version=empty
2024-02-14 02:38:19.069 [INF] LTND: Database(s) now open (time_to_open=106.471482ms)!
2024-02-14 02:38:19.069 [INF] LTND: We're not running within systemd or the service type is not 'notify'
2024-02-14 02:38:19.069 [INF] LTND: Waiting for wallet encryption password. Use `lncli create` to create a wallet, `lncli unlock` to unlock an existing wallet, or `lncli changepassword` to change the password of an existing wallet and unlock it.

Second Tab:

Now let's create a wallet, run the command below and follow through the wallet creation prompts

command:

 lncli1 create

output:

Input wallet password:
Confirm password:

Do you have an existing cipher seed mnemonic or extended master root key you want to use?
Enter 'y' to use an existing cipher seed mnemonic, 'x' to use an extended master root key
or 'n' to create a new seed (Enter y/x/n): n

Your cipher seed can optionally be encrypted.
Input your passphrase if you wish to encrypt it (or press enter to proceed without a cipher seed passphrase):

Generating fresh cipher seed...

!!!YOU MUST WRITE DOWN THIS SEED TO BE ABLE TO RESTORE THE WALLET!!!

---------------BEGIN LND CIPHER SEED---------------
 1. absorb     2. mammal    3. thank    4. isolate
 5. depart     6. trigger   7. legal    8. unhappy
 9. purchase  10. strong   11. effort  12. kangaroo
13. entry     14. solve    15. flower  16. mule
17. buyer     18. today    19. cancel  20. material
21. pupil     22. napkin   23. employ  24. ill
---------------END LND CIPHER SEED-----------------

!!!YOU MUST WRITE DOWN THIS SEED TO BE ABLE TO RESTORE THE WALLET!!!

lnd successfully initialized!

Let's go ahead and fetch some basic information about our node. Run the command below

command:

lncli1 getinfo

output:

{
    "version":  "0.17.0-beta commit=fn/v1.0.1-85-ge31d15989",
    "commit_hash":  "e31d1598932a814c2d44b774e5110746295df711",
    "identity_pubkey":  "02e0810d836946eebaeb9186c45ebb0c2d17294890ec67f488c9127de4d51dd3cd",
    "alias":  "02e0810d836946eebaeb",
    "color":  "#3399ff",
    "num_pending_channels":  0,
    "num_active_channels":  0,
    "num_inactive_channels":  0,
    "num_peers":  0, //👈🏿 take note of this number (our node is a bit lonely for now)
    "block_height":  547,
    "block_hash":  "10f9fb091fd2b83736ffde6621100d6db40b09fad3676c7930dce1821c31066a",
    "best_header_timestamp":  "1707215728",
    "synced_to_chain":  false,
    "synced_to_graph":  false,
    "testnet":  false,
    "chains":  [
        {
            "chain":  "bitcoin",
            "network":  "regtest"
        }
    ],
....
}

Time to create an address that would receive the bitcoin sent to the lightning node wallet

command:

lncli1 newaddress np2wkh

output:

{
  "address": "2N5qZ8TNWbrkaYxmsLYjEd8g6U7CrjDfHky"
}

Let's load up our Bitcoin wallet from the previous tutorial, send some juicy 100 Bitcoin from it to our lightning address above and then generate some blocks to give it some confirmations

"my oh my!!, what a man could do with some real 100 btc just sitting in a wallet 🤤. Alight alright that's enough buddy, don't be weird let's get back to the article."

Run the commands below in sequence

command 1:

bitcoin-cli loadwallet my_first_regtest_wallet

output:

{
  "name": "my_first_regtest_wallet"
}

command 2:

bitcoin-cli sendtoaddress 2N5qZ8TNWbrkaYxmsLYjEd8g6U7CrjDfHky 100

output:

3d36c8fc08f3ffd82bfa4e2aa33a63bf6c254bb46ffa1309fb9c7eb99adb3848

command 3:

bitcoin-cli generatetoaddress 10 "mhF5zQHNn7wzaaQTpzRmtsNgPgFF94fxeY"

output:

[
  "2fb9db66a292f9f37260be1490833d7cb4b1d5442478be67fd3d7c48281271c5",
  "7f284d403862117a21461da7cfdc3437a870fd608d0afe5e672c5c378ea2bc73",
  "4b4e867a02e49145f71b662fa4fea2a30eeff0d9a689953b655222ef2e336bd4",
  ...
]

Let's go ahead and check our lnd1 wallet balance

command:

lncli1 walletbalance

output:

{
  "total_balance": "10000000000", //👈🏿 sweet, our wallet was credited successfully
  "confirmed_balance": "10000000000",
  "unconfirmed_balance": "0",
  "locked_balance": "0",
  "reserved_balance_anchor_chan": "0",
  "account_balance": {
    "default": {
      "confirmed_balance": "10000000000",
      "unconfirmed_balance": "0"
    }
  }
}

📜 Prepare the second lightning node aka `lnd2` for some action

To get the second lnd node configured and running, repeat all the steps we followed above but this time around, funding the lnd2 wallet with some bitcoin is optional as this node would be on the receiving end of our transaction.

📜 Conclusion

We'll conclude here. Thank you for staying with us until the end of the second part. In the final part, we'll walk through connecting peers, opening payment channels, and other processes necessary for a valid lightning transaction.

📜 Useful links

part 1 of the series
